Multi-Functional Rotating Spreader: Structure, Advantages & Custom Solutions

Customized for Shandong Port Group — and Now in Service: How a Multi-Functional Rotating Spreader Is Built

HONFU recently delivered a customized multi-functional rotating spreader to Shandong Port Group, and the equipment is now in service. A rotating spreader is a specialized lifting device that integrates clamping, lifting and spatial orientation adjustment in a single unit. It is widely used for steel coils, plates, profiles, molds, containers and other loads that need to be turned or re-oriented during handling.

A multi-functional rotating spreader typically consists of the following components:

• Upper connection: lifting lug, shackle and pin shaft — connect to the crane hook and transmit the lifting force.
• Rotation mechanism: slewing bearing and bearing seat — carry combined loads and enable smooth rotation.
• Main frame: box-type beams and columns — provide overall rigid support.
• Clamping / load-carrying elements: clamps, lifting claws or V-shaped slots — designed according to the material form.
• Drive system: chains, linkages, hydraulic cylinders or gears — drive the clamping open-and-close action.
• Locking and braking: positioning pins and brakes — fix the angle securely once rotation is complete.
• Safety devices: anti-detachment hooks, limit switches and overload protection — safeguard every lifting operation.

Key Advantages of the HONFU Rotating Spreader

1. Laser welding process — uniform weld seams and stable structural connections ensure reliable, long-lasting performance.
2. Fully customizable — non-standard designs matched to your working conditions and tonnage, with module configurations adjusted to fit your actual production line.
3. Safety-first configuration — anti-detachment hooks, limit switches and other safety components deliver strong risk control throughout operation.
4. End-to-end support — from structural selection to after-sales communication, we keep the equipment closely matched to your site requirements.

Selection tip: A rotating spreader turns loads around a vertical axis, while a turning spreader flips loads around a horizontal axis — the two have fundamentally different structures. When selecting, first confirm the material form, required rotation angle and load capacity, then decide on the drive method (manual, hydraulic or motorized).

Need a Custom Rotating Spreader? Contact HONFU

Shandong Hongfu Technology Co., Ltd. (HONFU) always puts customer needs first. We provide customized rotating spreader solutions for lifting scenarios across industries — from steel and manufacturing to logistics and port operations.

Tell us your material type, rotation requirements, tonnage and site conditions, and our technical team will recommend or design the right configuration for you.
